Ceramic Insulated Water Cooled Induction Heating Roller For Thermal Print And Precoat Lamination
Product Features
Whole-body Uniform Heating: Modified electromagnetic induction configuration limits roller surface temperature gap in ±1℃ scope, can be deployed for low medium high different temperature processing environments.
Stable Precision Temperature Control: High-sensitive sensing elements keep temperature change within 0.1℃, matched with ceramic thermal isolation and water-cooled coil to finish steady production under 600℃.
Intrinsic Safety Performance: Pure electromagnetic heating mode avoids pressure deformation, blasting failure and medium leakage risks that always trouble thermal oil heating roller equipment.
Green Running Merit: Cancel thermal oil circulation and steam auxiliary pipeline, no fluid leakage, no on-site pollution and no toxic gas emission during long-time equipment operation.
Cost Saving via Energy Efficiency: Cut running power by 50~70% compared with conventional heated rollers, the roller’s overall heating rate doubles for higher production efficiency.
Technical Specifications
| Material |
High-quality 45# steel, alloy steel |
| Roller Surface Temperature Difference |
≦±1℃ |
| Heating Method |
Electromagnetic induction heating |
| Surface Treatment |
Hard chromium plating, Teflok, spray ceramic or tungsten carbide |
| Processing Accuracy |
≤0.005mm |
| Straightness Runout |
≤0.01mm |
Application Fields
Printing, packaging, textiles, non-woven fabrics, thermal transfer printing, laser anti-counterfeiting, electronics, specialty paper, paper drying, pre-coated film lamination, laminated iron/aluminum production, optical films, stretch films, PTFE films, solar panel lamination, lithium battery components, PTFE coated filters, copper clad laminates, polyimide synthesis, chemical fibers, carbon fibers, sheet calendering, rubber/plastic/metal plate processing, high-temperature material composites.
About Huatao Group
Located in Shijiazhuang, Hebei, China, we specialize in manufacturing rollers for BOPET, BOPP, CPP lines, slitters, metalizers, and laminating machines. We welcome partnerships to create a prosperous future.
